used plastic centrifugal pump with pressure vessel

details to article: 29083

description: Designed to ISO2858 the ECC (close coupled) Plastic Mechanical Seal Pumps are heavy duty pumps.

Producer:	Crest Pumps
Typ:	ECC 50-32-160
Year of manufacture:	2017
Pieces:	1

technical data Delivery rate  1 m³/h (rated capacity) Diameter  170 mm (Impeller Diameter) Material  PP () Material  Stahl (plastic parts are supported by a robust steel) Power  4 kW Rotations  2900 1/min Serial number  RN 5777 Length  mm Height  mm Width  mm Weight  kg Accessories  (Pressure boiler, type SSE 10 vessels by Aesseal) Volume  10 l Pressure  16 bar Temperature  -20 bis +100 °C Material  Edelstahl (Container made of 304 stainless steel, surface glass-blasted) Serial number  ACWO35689 send request      more info: Tipp Umwelt- und Verfahrenstechnik GmbH Obere Hilgenstock 34 D-34414 Warburg Tel.: +49 5641 7447-0 Fax: +49 5641 7447-28 email: mail@tipp-international.de Internet: www.tipp-international.de
